LB300 - LF350
Fixed table

LC400 - LC500
Rotating table

LP500/200
Oscillating table

LC400 Closed

    Vertical axis grinding machines

    5 models with fixed table (LB300, LF350), with rotating table (LC400, LC500), with oscillating table (LP500/200).

    Grindable surface:
    - from 330x140 mm up to 500x200 mm
    - from Ø 300 mm up to Ø 500 mm

    Download general catalogue

    Manufacturing features

    All the machines are provided with:

    • Maximum structural rigidity
    • Wheelhead with special dynamically balanced electrospindle (2.2-3.0 kW)
    • Quick vertical feed on handwheel
    • Micrometric feed through coupled ratchet
    • Electrical system with low voltage controls (pelv 24V)
    • Cooling system with settling tank and electric tank
    • User-friendly
    • Maximum reliability

    Rotary table models:

    • Toothed belt drive and planetary gear unit
    • Electro-permanent magnetic chuck with standard electronic control unit

    Oscillating table models:

    • Toothed belt drive
    • Electro-permanent magnetic chuck with standard electronic control unit

    The vertical axis grinding machines DELTA are machines designed and made with modern technologies and on the basis of a long and consolidated experience in the sector (over 20,000 units sold all over the world).

    Scope of use

    • Precision mechanics
    • Aeronautical, shipbuilding, motor, and automotive industries, wood processing, machine tools, household appliances, food industry
    • Sheet metal processing to sharpen punches and dies
    • Material testing laboratories
    • Toolrooms
    • Technical and vocational schools

    Automation levels (accessories)

    L11

    Hundred automatic feed

    In order to improve the performance of the rotary table grinding of the LC series machines, it is possible to provide them with automatic centesimal feed of the wheelhead (L 11), an accessory allowing to carry out automatic grinding cycles.
    It includes a device which synchronizes the movements on the vertical axis of the wheelhead with the rotary motion of the work table; every two revolutions of the table, the wheelhead carries out the pre-set feed.
    The max removal in every work cycle is 1 mm which can be obtained with feeds of 0.005, 0.010 and 0.015 mm.

    L11E

    Electronic micrometric downfeed with digital readout

    Is the new electronic device for micrometric down-feed with digital readout applicable to all LC series vertical spindle grinding machines.
    A big display visualizes with micrometric resolution the position of the vertical axis that can be moved with the jog buttons or with the micrometric electronic hand-wheel. The cycle is completely automatic.
    The cycle parameters are: material to be removed, increment (min 0,001 mm), number of spark out, number of revolution of the table per increment.
    At the end of the cycle the head moves up, the grinding wheel motor, the coolant electro-pump and the table stop.

    Accessories catalogue

    for vertical axis grinding machines
    Download
